Gingiva 3D
Gingiva 3D from Garreco Print is perfect for manufacturing soft tissue, and gum-like parts for dental implant models. This soft pink resin is optimized for Liquid Crystal Display (LCD), Digital Light Processing (DLP), and Stereolithography (SLA) 3D printers.
Product Description
Gingiva 3D is a pink-colored photopolymer resin. It is a soft and flexible material that can be combined with Model 3D Pro Beige or Model 3D Pro Grey material. Gingiva 3D opens the possibility to create the soft part for highly precise models, bridges, and implant superstructures. Gingiva 3D is easy to use on open MSLA / LCD, DLP, and SLA 3D printers in the 385 – 420nm range. With its soft and flexible properties, Gingiva 3D is perfect for the production of gum parts and soft tissue which supports dental implant models and C&B projects.
Sizes and Colors Available
1kg (1000g) Soft Pink
Technical Properties for Gingiva 3D
POLYMER PROPERTIES
| Mechanical Properties | 5 minutes UV-curing in water & 25 minutes UV-curing in air at 40°C[1] | ||
|---|---|---|---|
| Description | ASTM Method | Metric | Imperial |
| Tensile strength | D638 | 2.2 MPa | 0.31 ksi |
| Tensile modulus | D638 | 11.9 GPa | 1.73 ksi |
| Elongation at break | D638 | 80 – 120% | 80 – 120% |
| Shore A Hardness | D2240 | 64 | 64 |
| Water sorption | D570-98 | 14.8% | 14.8% |
| Degradation temperature | Internal method | >250°C[2] | >482°F[2] |
LIQUID PROPERTIES
| Description | Value |
|---|---|
| Appearance | Opaque pink liquid |
| Viscosity | 950 cps at 25°C |
| Density | 1.18 g/cm3 |
| Ec | 14.22 mJ/cm2 |
| Dp metric | 0.22 mm |
| Dp imperial | 8.64 mils |
[1]Post-cured 5 minutes in a transparent jar with water followed by 25 minutes UV post-curing at 40°C in aur. These values may vary and depend on individual machine processing and post-curing. [2]Discoloration and increased rigidity at 140°C. No cracking in part up to 250°C / 482°F.
